CBB81 High Voltage Metallized Polypropylene Film Capacitor

Graphic
Detail

CBB81 High Voltage Metallized Polypropylene Film Capacitor

Name: CBB81 High Voltage Metallized Polypropylene Film Capacitor
Rating: 4.6 (81 reviews)

■ 特点及用途

● 金属化� �丙烯膜箔式，卷绕结构

● 低� ��耗、内部温升小

● 相对于频率和温度的变� ��电性能稳定

● ;适用于高� �冲,大电流电路

Parameters

■ 特点及用途

● 金属化� �丙烯膜箔式，卷绕结构

● 低� ��耗、内部温升小

● 相对于频率和温度的变� ��电性能稳定

● ;适用于高� �冲,大电流电路

Product Details

■ Features and uses

● Metallized polypropylene film foil, winding structure

● Low loss, small internal temperature rise

● Stable electrical performance relative to frequency and temperature changes

● Suitable for high pulse and high current circuits

■ Technical requirements

● Reference standard: GB/T 10190 (IEC 60384-16)

● Climate category: 40/105/21

● Rated temperature: 85℃

● Operating temperature: -40 ℃ ~105 ℃ (+85 ℃ ~ +105 ℃ voltage derating 1.25%UR per ℃)

● Rated voltage: 800V; 1000V; 1250V; 1600V;

● Capacitance range: 0.001~0.1μF (1KHz)

● Nominal capacitance deviation: ±5%; ±10%; ±20%

● Withstand voltage: 1.75UR, (5S)

● Insulation resistance:

CR≤0.1μF： ≥30000MΩ（100V,1min ）

● Loss tangent: ≤0.001 (1KHz)

■ Dimensions(mm)

RV	800VDC					1000VDC					1200VDC					1600VDC
Size Cap(uF)	IN	H	T	P	die	IN	H	T	P	die	IN	H	T	P	die	IN	H	T	P	die
0.001	18	10	5	15	0.8	18	10.1	5.7	15	0.8	18	10.1	5.7	15	0.8	18	10.4	6	15	0.8
0.0012	18	10	5	15	0.8	18	10.5	6	15	0.8	18	10.5	6	15	0.8	18	10.8	6.4	15	0.8
0.0015	18	10	5	15	0.8	18	11	6.5	15	0.8	18	11	6.5	15	0.8	18	11.3	6.9	15	0.8
0.0018	18	10	5.5	15	0.8	18	11.9	6.7	15	0.8	18	11.9	6.7	15	0.8	18	12.3	7.1	15	0.8
0.0022	18	10.5	5.5	15	0.8	18	12.5	7.3	15	0.8	18	12.5	7.3	15	0.8	18	12.9	7.7	15	0.8
0.0027	18	10.5	5.5	15	0.8	18	13.1	7.9	15	0.8	18	13.1	7.9	15	0.8	18	13.1	7.9	15	0.8
0.0033	18	10.5	5.5	15	0.8	18	13.8	8.6	15	0.8	18	13.8	8.6	15	0.8	18	13.8	8.6	15	0.8
0.0036	18	10.5	5.5	15	0.8	18	11.7	6.5	15	0.8	18	11.7	6.5	15	0.8	18	11.7	6.5	15	0.8
0.0039	18	10.5	5.5	15	0.8	18	12	6.7	15	0.8	18	12	6.7	15	0.8	18	12	6.7	15	0.8
0.0047	18	10.5	5.5	15	0.8	18	12.5	7.3	15	0.8	18	12.5	7.3	15	0.8	18	12.5	7.3	15	0.8
0.0056	18	10.5	5.5	15	0.8	18	11.5	6.2	15	0.8	18	12.5	6.8	15	0.8	18	12.6	7.4	15	0.8
0.0068	18	10.5	5.5	15	0.8	18	12	6.8	15	0.8	18	12.5	6.8	15	0.8	18	13.7	8	15	0.8
0.0082	18	12	6	15	0.8	18	12.5	7.3	15	0.8	18	13	7.5	15	0.8	18	14.4	9.2	15	0.8
0.01	18	12	6	15	0.8	18	12	6.5	15	0.8	18	14	8	15	0.8	18	15.3	10	15	0.8
0.012	18	12	6	15	0.8	18	12.5	7	15	0.8	18	14.5	9	15	0.8	18	16.1	10.9	15	0.8
0.015	18	12	6	15	0.8	18	13.5	7	15	0.8	18	15.5	10	15	0.8
0.018	18	12	6	15	0.8	18	14	7.5	15	0.8	18	17	11	15	0.8
0.022	18	12	6.5	15	0.8	18	14	8.5	15	0.8	18	18	12.5	15	0.8
0.027	18	14	7	15	0.8	18	15.5	9.5	15	0.8	23	17.5	10	20	0.8
0.033	18	14.5	7.5	15	0.8	18	15.5	10	15	0.8	23	18.5	11	20	0.8
0.036	18	15	8	15	0.8	18	16	10.5	15	0.8	23	19	11.5	20	0.8
0.039	18	15.5	8.5	15	0.8	18	16.5	11	15	0.8	23	19.5	12	20	0.8
0.043	18	16	9	15	0.8	18	18	11	15	0.8	23	20	13	20	0.8
0.047	18	16.5	9.5	15	0.8	18	18.5	11.5	15	0.8	23	20.5	13.5	20	0.8
0.056	23	15.5	8	20	0.8	23	17.5	11	20	0.8	23	22	15	20	0.8
0.068	23	18	8	20	0.8	23	18	12	20	0.8
0.082	23	19	9	20	0.8	23	20	13	20	0.8
0.1	23	20	10	20	0.8	23	22	15	20	0.8

Note: Special specifications are produced according to user requirements
